Pressure Gauge Bourdon Tube Tip / End Cap

Precision Brass Sealing Component for Bourdon Tube

Critical brass end cap fitted to the free end of the Bourdon tube—ensures leak-proof sealing and smooth motion transfer to the gauge mechanism for accurate pressure readings.

The Bourdon Tube Tip, also known as the End Cap, Free End, or Sealed End, is a vital component in pressure gauge manufacturing. This compact yet highly critical part is attached to the free end of the Bourdon tube to seal it completely and provide a dependable connection point for the linkage mechanism. As pressure enters the Bourdon tube, it tends to straighten; the tip moves accordingly and transfers this motion through the linkage to internal gears, which rotate the pointer for accurate readings. Typically fixed using brazing or welding, it forms a strong, leak-proof joint even under high pressure. Manufactured from premium brass with a natural finish, it offers excellent corrosion resistance, durability, and precision performance for OEM and instrumentation use.
